2.3.4 EH-2080 Fully Automatic Urinary Sediment Analysis System
Produced by Mindray, it can automatically adjust the focal length of the microscope, and its patented technologies improve the image clarity and stability.
1. Structure: It is composed of automatic sampler, automatic digital microscope, sample injector, multi-channel counting cell, and computer control processing system.
2. Test principle: Dynamic intelligent focusing technology(DIF), coordinate positioning and tracking technology, and machine vision technology.
3. Parameters: The testing speed is 100 T/H. It can test 16 items of parameter including RBC morphology.
4. Technological innovation: (1) The patented DIF technology, combined with flow counting cell, machine vision technology and coordinate positioning tracking and identification technology, realizes the quantitative detection of various urine formed elements without the need for fixed focus fluid, and greatly reduces the cost of laboratory testing. (2) The problem of focal length control in the detection process is solved, the backhaul difference caused by environmental factors is eliminated, and the stability of focal plane is effectively maintained.
