2.2.3 AVE-752 Full Automated Urine Analyzer
Produced by AVE, it has a high degree of automation, and the front end is equipped with automatic sample delivery device.
1. Structure: It consists of automatic sample delivery device, sample processing device, test strip convey device, dry chemical analysis device, physical test device, and central control unit.
2. Test principle: Charge coupled device (CCD) detecting technique.
3. Parameters: The testing speed is 240 T/H. It can test 14 items of dry chemistry and five items of physical parameter, and provide ACR.
4. Technological innovation: (1) It adopts innovative cassette strip loading system, so as to ensure that the test strips are clean and free of pollution, and to avoid the interference with the test results caused by direct manual contact. (2) The patented strip distribution technology and device ensure that it outputs test strips automatically and singly on front side, place test strips accurately without jamming. (3) It adds unique sample sprinkling technology. (4) The test results are photographed and stored by CCD to facilitate manual review and traceability.
